Applications锛
vibration scale allows to doze amount of a product directly into the forming tube of VFF&S bagger. High accuracy and fast rate of the scale guarantee its reliable and long-term service. vibration scale is mainly used when packaging granular products: peanuts, walnut, pine seed etc other roasted seeds and nuts.
Features锛
All servo vertical form fill seal (vffs) baggers for faster operating speeds;
Quick changeover of sealing jaws to switch between laminated and non-laminated film;
Unique center-lining features for simple, tool-less and quick changeover of forming tubes and film rolls;
Film roll changes achieved in less than a minute with our 2-position film roll feature
Vertical form fill seal bagging machines with traditional heat sealing or Ultrasonic welding;
As a Rockwell Automation Machine Builder Partner, our vffs baggers utilize Rockwell Automation ControlLogix platform;
We offer the only zipper applicator that is integrated into the film cage, which eliminates rejects caused by poor zipper placement;
Our vertical form fill seal (vffs) baggers can change speed based on an up-stream signal, without operator intervention.
Product Name:
Vertical Form Fill Seal Machine , Vffs Machine , Form Fill Seal Machine,500 Gram Packing Machine, , Plastic Pouch Packing Machine ,Paper Filling Machine , Small Weighing And Packing Machine , Vffs Baggers , Pouchfill Packaging , Full Automatic Packaging Machine , Pouch Bag Packaging Machine , Vertical Fill And Seal Machines , Automatic Bag Filling And Sealing Machine , Chips Pouch Packing Machine , Vertical Form Fill Seal Machine Manufacturers , Nitrogen Bagging System , Vffs Machine Manufacturers , Automatic Atta Packing Machine Manufacturers , Form Fill And Seal Plastic ,Automated Food Packaging Machine锛孲nack Food Packaging Machine 锛孨uts Filling Machine , Nuts Packing Machine Price锛 Gummy Filling Machine.
Technical Data锛
Model | ZR-260B |
Bag Type | Pillow bag, Gusseted bag/Flat bottom bag |
Operation Mode | Intermittent |
Speed | Up to 100 bags/min |
Bag Length | 50-340mm |
Bag Width | 80-260mm |
Reel Film Width | 420mm |
Film Thickness | 0.04-0.12mm |
Reel Outer Dia | 肖450mm |
Reel Inner Dia | 肖75mm |
Voltage | AC 220V/ 50HZ锛1phase or per customer needs |
Power Consumption | 3KW |
Compressed Air Requirement | 0.6MPa锛0.36 M3 / Min |
Dimension | 1600x1217x1680mm锛圠 x W x H锛 |
Weight | 800KG |
