Applications锛
vertical form fill and seal (VFFS) machinery. product feeders, auger fillers and checkweighers. Iapack provides a complete vertical filling solution capable of handling any product that requires laminate film structures and polyethylene films. Zengran Pack of filling methods are integrated with the zengranpack line to package products such as spices and seasonings, flour based products, coffee, snack foods, candy, chemicals and liquids.
Features锛
Fills 70 bags per minute.
Forms and fills 0.5 oz to 5 lbs.
Package sizes 2.0鈥 x 2.0鈥 to 8鈥 x 14鈥
鈥淭ool-less鈥 changeover
Common, off-the-shelf component types.
PLC control stores 50 routines with a 7-inch widescreen color HMI.
Technical parameters锛
| Model | ZR-200 |
| Bag Type | Pillow bag, Gusseted bag/Flat bottom bag |
| Operation Mode | Intermittent |
| Speed | Up to 70 bags/min |
| Bag Length | 50-280mm |
| Bag Width | 70-180mm |
| Reel Film Width | 420mm |
| Film Thickness | 0.04-0.12mm |
| Reel Outer Dia | 肖350mm |
| Reel Inner Dia | 肖75mm |
| Voltage | AC 220V/ 50HZ锛1phase or per customer needs |
| Power Consumption | 3KW |
| Compressed Air Requirement | 0.6MPa锛0.36 M3 / Min |
| Machine Size | 1480x1020x1400mm锛圠 x W x H锛 |
| Weight | 700KG |
Product Name:
Vertical Form Fill Seal Machine , Vffs Machine , Form Fill Seal Machine , Vffs Packaging Machine , Vertical Packing Machine , Form Fill And Seal Machine , Vertical Form Fill Machine , Vertical Form Fill And Seal Machine , Fill Seal Machine , Vertical Form Fill Seal Packaging Machines , Vffs Packing Machine , Form Fill Machine , Vertical Ffs Machine , Form And Fill Machines , Vertical Form Seal Machine , Fill Seal Packaging Machine , Form Fill Seal Bagging Machine , Form Fill Seal Packaging Machine , Vertical Packing Sealing Machine , Form Fill And Seal Packaging Machines , Small Vertical Form Fill Seal Machine , Vffs Bagging Machine , Vertical Form Fill And Seal Packaging Machines , Form Fill And Seal Bagging Machine , Fill And Seal Machines , Form Fill Seal Packaging , Vffs Packaging , Form Fill And Seal Packaging , Form Fill And Seal Packaging Film , Vertical Form Fill Seal Packaging.
Packing system composition锛
1. Weighing Equipment: 1/2/4 head linear weigher, 10/14/20 heads multihead weigher, volume cup...
2. Infeed Bucket Conveyor: Z-type infeed bucket conveyor, big bucket elevator, inclined conveyor...
3.Working Platform: 304SS or mild steel frame. (Color can be customized)
4. Packing machine: Vertical packing machine, four side sealing machine, rotary packing machine...
5.Take off Conveyor: 304SS frame with belt or chain plate.
