Applications
It's configured to produce four corner edge seal stand-up bags, quad seal bags, it's also available to do pillow and gusset bag by option.
All kinds of grain material, sheet material, strip material and abnormity material which such as candy, melon seeds, chips, peanut, nutlet, preserved fruit, jelly, biscuit, confect, camphorball, currant, almond, chocolate, filbert, corn, Potato Crisps, pet foodstuff, dilatant foodstuff, hardware and plastic can be weighed by the ration.
Features
User friendly PLC controller & Touch screen interface
Unique back-seal design are extremely flexible to run quad seal, pillow, gusset bag.
Independent temperature zones
Servo-driven film transport and cross sealing jaw
Vacuum pump assists film transport
Guarding style allows greater access & easy maintenance
Fully enclosed stainless steel & aluminum construction
Robust long-life construction
Technical Specifications
| Model | ZR-540Q | ZR-730Q | |
| Bag style | Quad Seal Bag, pillow and gusset bag | ||
| Bag length | Up to 340mm (13.4'') | Up to 420mm (16.5'') | |
| Bag width | 80 to 200mm (3.1'' to 7.9'') | 100 to 240mm (4'' to 9.4'') | |
| Bag Side depth | 50 to 100mm (2'' to 3.9'') | 50 to 120mm (2'' to 4.7'') | |
| Edge Seal width | 5 to 10mm (0.2'' to 0.4'') | ||
| Film width | 鈮540mm (21.3'') | 鈮730mm (28.7'') | |
| Voltage | AC220V/50Hz, 1phase or Per customer specification | ||
| Power Consumption | 3KW | 4KW | |
| Compressed Air Requirement | 0.6 MPa, 0.36 M3锛弇in ( 87 Psi, 12.7cfm)鈥籄bove parameters are able to be customized properly as requests. | ||
Product Name:
Vertical Form Fill And Seal Machines , Vffs Parts , Single Serve Packaging Machine , Vertical Form Fill , Automatic Packing And Sealing Machine , Laminated Packaging Machine , Ultima Vertical Form Fill Seal Machine , Weight Packaging Machine , Gusset Bag Packaging Machine, Packaging Machine Distributor , 500 Gram Packing Machine, , Plastic Pouch Packing Machine ,Paper Filling Machine , Small Weighing And Packing Machine , Vffs Baggers , Pouchfill Packaging , Full Automatic Packaging Machine , Pouch Bag Packaging Machine , Vertical Fill And Seal Machines , Automatic Bag Filling And Sealing Machine , Chips Pouch Packing Machine , Vertical Form Fill Seal Machine Manufacturers , Nitrogen Bagging System , Vffs Machine Manufacturers , Automatic Atta Packing Machine Manufacturers , Form Fill And Seal Plastic.
We have been producing vertical packing machines, multi-heads weighers and linear weighers, filling units, food processing machines, vertical and Z type elevators, various conveyors and special projects since 1995. Since it was established, iapack following and implementing new technology, have been pioneers on initiation and development of many innovations. Our main aim is to produce qualified and effective machines for presenting our customers much more qualified facilities appropriate for developing technology and international standards. With our experience for 20 years in the market, we can build whole food processing factories from harvesting to final packaging. Our products are with the best quality and also competitive prices. Wishing to be together for many years.
