vertical form fill seal continuous motion bagger

vertical form fill seal continuous motion bagger,Vertical Filling Machine,Vertical Form Fill Seal Packaging Machines

Applications

Vertical FF&S Intermittent Motion Bagger, designed for packing products into bags of max width 250 mm, wide range of products like loose food, plastic, metal etc. Our machines are capable of producing a considerable variety of bags, for instance: flat bags, bricks, side gusset bags, stabile with 4 sealed corners, euro slot bags, handle etc:

Food loose
Fresh, frozen
Granulates
Sweets
PET food
Cookies
Coated nuts
Frozen fruits, vegetables
Metal, plastic parts

Features

PLC control with Touch-Screen HMI
Servo technology with high performance
Simple and fast bag size changeover without tools
Precision film auto tracking, length registered by photo-sensor or encoder
Vacuum pump assists film transport
Ajustable dwell time for better looking seals and increased packaging speeds
Compact, robust and long-life construction

Technical Data

Bag Styles	Pillow Bag
Bag Width	80 to 260mm (3.1 to 10.3")
Bag Length	50 to 340mm (2.0 to 13.4")
Product Characteristic	Granules, Powders, Liquids, Pastes
Dosing System Compatible	Volumetric Cup , Linear Scale , Multi-Head Scale
Running Motion	Continuous
Working Efficiency	120bpm
Control By	PLC with HMI Touch Screen
Date Coding Can Be	Hot Stamping Coder, Thermal Transfer Coder, Label Applicator
Options Available	Perforation, Dust Absorb, Seal PE Film, SS Frame, SS & AL Construction, Nitrogen Flushing
Film & Reel	0.04-0.12mm Real Max.Dia.400mm(15.7") Width 540mm (15.7")
Power & Voltage	3.0KW
Compress Air	Need 0.6 MPa 0.36 M3
Dimensions	1650 x 1140 x 1650mm (65.1 x 44.9 x 64.9'')
Machine Weight	800 KGS

Optional Device

1.Tear notch device
2.Hole punch device.
3.Static eliminator.
4.Gusset device.
5.Date printing.
6.Prevention broken bag device.
7.3 side seal device.
8.Nitrogen gas flushing.
9.Air flushing & Air exhaust device.
10.Heavy product bag support device.
11.PE film sealing device.
12.Prevention broken bag device.
