Applications:
Suitable for many kinds of measuring equipments, and package different kinds of products; such as puffy food, shrimp roll, peanut, popcorn, cornmeal, seed and sugar etc. which shape is roll, slice and granule.
Features:
A. Double transducer control, flexible bag length cutting.
B. Human-machine operation, convenient and quick parameter setting.
C. Self-diagnostic function, failure can be clearly displayed.
D. High sensitivity optical electric color mark tracking enable accurate bag sealing and cutting.
E. Separate PID temperature controller, suitable for various packing materials.
F. Simpel driving system, reliable performance and convenient maintenance.
G. All the controls are achieved by software, convenient for function adjusting and upgrading.
Technical Data:
| Type | ZR-520V | ZR-420V |
| Bag length | 50-400mm(L) | 50-300mm(L) |
| Bag width | 100-250mm(W) | 60-200mm(W) |
| Max roll film width | 520mm | 420mm |
| Packing speed | Max.180bag/min | Max. 180 bag/min |
| Air consumption | 0.4m3/min 0.7Mpa | 0.3m3/min 0.7Mpa |
| Power voltage | 5KW 220V 50/60HZ | 4.8KW 220V 50/60HZ |
| Dimension | 1600(L)脳1170(W)脳1610mm(H) | 1380(L)脳980(W)脳1400mm(H) |
| Net weight | 950KG | 600KG |
Optional Device:
Chain bags & multi-bags half cut-off function.
Gusset device.
Bag support.
Gus flushing device.
Air flushing & Air expeller device.
4 side seal device.
PE sealing system.
Date printing.
