Product description
Integrated with piston filler as the dosing system, ZRLP series bagger is applied to packing liquid or paste, like water, juice, sauce, vinegar, honey, ketchup, mayonnaise, shampoo and etc.
Features
High-speed capability up to 60bpm
Intelligent chip controller with 5鈥 LCD interface
Frequency converter for option
Independent temperature adjustment
Easy for operation and maintenance
Limitless speed adjustor for wider speed range
304# stainless steel frame for option
High performance at low cost
Options
Hot stamping date coder
Gas flushing device
Round hole punching device
Chain-bag device
Air reel film holder
Technical Specifications
| Model | ZRLP-320 | ZRLP-520 | ZRLP-3S-320 | ZRLP-4S-320 |
| Bag style | Pillow bag | Pillow bag | 3-side-seal bag | 4-side-seal bag |
| Speed (bpm) | 24-60 | 15-40 | 15-40;24-60 | 24-60 |
| Packaging Weight (ml) | 锛40; 20-100 | 500-2000 | 锛40; 20-100; 50-300 | 锛40, 20-100; 锛25, 20-75, 50-150 |
| Bag length(mm) | 30-180 | 100-310 | 30-150 | 30-150 |
| Bag width(mm) | 25-145 | 100-240 | 25-145 | 25-145 |
| Film width(mm) | 鈮300 | 鈮500 | 鈮280 | 鈮270 |
| Reel film width | 30-100mic. | |||
| Electrical | 220V/50HZ, 1Phase or as per customization | |||
| Power consumption | 1.8kw | 2.5kw | 1.8kw | 2.2kw |
| Machine weight(kg) | 280 | 350 | 280 | 280 |
Application&bag type
Applicable to a variety of powder packaging , such as milk powder, coffee powder, flour, cornstarch, washing powder and other products.
Applicable Pouches: Pillow / back sealing /flat pouch, 3/4 side sealing pouch,stick/triangle pouch,gusseted/quatro pouch,
doypack.
Our warm service
1. Manules / Videos of machine installation, adjusting, setting, maintenance are available to you.
2. If any problems occured and you can not find out the solutions, Telecom or Online face to face communication are available around 24 hours.
3. Shilong engineers & technician are ready to your countries for services if you agree to pay the expenditure.
4. The machine will have one year warranty. During the warranty year, if any of the parts are not broken because of misoperation, we guarantee to replace free of charge. The warranty will start counting after the machine is sent out and we received the B/L.
5. Shilong has an independent team for after-sale service. If any emergency please call the saleman or our after-sale's manager.
