Application
Pyramid tea bag is a popular and attractive type of packaging method of tea.
Be used for automatically packing products as green tea, black tea, flower tea, health tea, medicine tea, and granule and so on.
Features
This unit can perform either three sides sealing or triangle teabag. just need single bond to change the bag between three sides sealing and triangle shape.
Packaging capacity: 3000bags/h (Determined by packing material).
Applicable packing materials: Nylon film with thread and label.
The precision volumetric metering way very easily in the transformation of filling material. Electronic scale metering can be collocated according to the material.
Human-Computer Interface, Omron PLC control, adopted the Panasonic double Servo motor to make the bag. Supplied complete setting functions. Easy operating.
Main motor overload protection device.
Packaging material tension automatic adjustment device.
The machine will automatically stop when issued the warning.
Technical Parameter
| Working Capacity | 40-50 BPM |
| Measuring Method | Sliding volumetric type |
| Sealing Type | High frequency sealing |
| Shape of Packing | Pyramid or square type |
| Mesh of Packing | Standard mesh for high frequency sealing |
| Width of Mesh | 120mm, 140mm ( 160mm, 180mm can be customized ) |
| Volume per Pack | 2卤0.5 g / bag ( other volume can be customized ) |
| External diameter of mesh roll | 鈮の350銕 |
| Inside diameter of mesh roll | 桅76銕 |
| Power Supply | Per client鈥檚 specifications, 0.5Kw |
| Air Supply | 鈮0.6Mpa |
| Operator | 1 operator |
| Machine Dimension | L 880mm x W 640mm x H2200mm |
| Machine Weight | 350kg |
Product Name:
Vertical Form Fill Seal Machine,Form Fill Seal Bagging Machine , Form Fill Seal Packaging Machine , Vertical Packing Sealing Machine , Form Fill And Seal Packaging Machines , Small Vertical Form Fill Seal Machine , Vffs Bagging Machine,Quad Bag Packing Machine , Quad Seal Bag PackagingMachine,Granule Packing Machine Factory,Weight Packaging Machine , Packaging Machine Distributor , 500 Gram Packing Machine.Granule Packing Machine Factory锛Quad Bag Packing Machine , Quad Seal Bag Packaging Machine ,Vertical Packing Sealing Machine,Automatic Filling Packing Machine锛Food Pouch Filling Machine锛Vertical Form And Fill Machine , Vertical Sachet Filling Machine锛Vertical Filling Machine锛Coffee Filling Machine.
Our Services
1.Manufacture experience, strong R&D department.
2.Exported to more than 1000 customers from more than 50 countries.
3.We promiss machine keep working over 10 years in good working condition. Fewer easy broken parts, easy to change.
4.Intelligent PLC control system,easy operate, more hommization.
5.One year warranty time, lifelong free service, 24 hours online service.
