Applications
Applicable for weighing of granular, powdered or other types of products with uniformed-shape, such as sugar, rice, chicken essence seasoning , seeds, salt, powdered milk, coffee, seasoning, etc.
Features
7鈥漜olor touch screen, multi-language option and softwareupgraded through USB.
Machine body with SUS304/316 for option and IP65 dust / waterproof design.
Factory parameter recovery function, able to preset 99 product parameters to meet a wide range of customers鈥 needs.
Automatic amplitude adjustment for more convenient operation.
Each hopper can function as a single scale.
Achieving blended weighing and packaging for 8 types of products
Optional single/double discharge timing hopper. Connecting with one or two packaging machines or double-row packaging machine to achieve high-speed weighing and packaging.
Hopper door opening driven by step motor to make the operation faster and more stable.
Modular control system for easy maintenance and low cost.
Technical Data
| Max. Weighing (one hopper) | 300g |
| Accuracy | x (0.5) |
| Max. Scale Interval | 0.1g |
| Max. Speed | 170 WPM |
| No. of Weighing Hopper | 8 |
| Hopper Volume | 0.5L / 1.2L |
| Control System | MCU |
| HMI | 7鈥欌 color touch screen |
| Power Supply | AC220V 卤10% 50HZ/60HZ, 1.6KW |
| Machine Dimension | 1,120(L)*736(W)* 1,130(H)mm |
| Packing Dimension | 1,315(L)*1,100(W)*1,458(H)mm |
| Net Weight | 215kg |
| Gross Weight | 315kg |
