Application锛
Mainly applicable in temporary storage and transportation to conveying equipment for granular products such as puffed food, grain, plastic pellets, dried fruit, etc.
Main Function & Features锛
1. The machine uses electromagnetic principle as the power to vibrate the product to the conveying equipment to realize automatic feeding process.
2. To form a continuous or intermittent automatic weighing and packaging line with other equipment.
3. Simple maintenance, easy disassembly and convenient cleaning.
Technical Parameters锛
Contents | Specifications | |
Machine | Independent vibrating feeder | Fast rewinding feeder |
Body Material | SUS304 | |
Frame Material | carbon steel with powder coating | |
Vibrating Pan Length | 826mm | 2667mm |
Exit Height | 530mm / 550mm or per requirement | |
Silo Volume | 150L/200L | N/A |
Max. Capacity | 8m鲁/h | 8m鲁/h |
Power Supply | single phase 220V 50HZ/60HZ | |
Power Consumption | 0.75KW | 1.5KW |
Total Height (mm) | custom-made per requirement |
