Applications锛
All kinds of grain material, sheet material, strip material and abnormity material which such as candy, melon seeds, chips, peanut, nutlet, preserved fruit, jelly, biscuit, confect, camphorball, currant, almond, chocolate, filbert, corn, Potato Crisps, pet foodstuff, dilatant foodstuff, hardware and plastic can be weighed by the ration.
Features锛
1.Efficient: Bag - making, filling, sealing, cutting, heating, date / lot number achieved in one time;
2. Intelligent: Packing speed and bag length can be set through the screen without part changes;
3. Profession: Independent temperature controller with heat balance enables different packing materials;
4. Characteristic: Automatic stop function, with safe operation and saving the film;
5. Convenient: Low loss, labor saving, easy for operation and maintenance.
Technical Specifications锛
Model | ZR-420A | ZR-520A | ZR-720A |
Film Width | Max.420MM | Max.520MM | Max.720MM |
Bag Length | 80-300MM | 80-350MM | 100-500MM |
Bag Width | 60-200MM | 100-250MM | 180-350MM |
Film Roll Diameter | Max.320MM | Max.320MM | Max.320MM |
Film Thickness | 0.04-0.12MM | 0.04-0.12MM | 0.04-0.12MM |
Packing Speed | 5-60Bag/Min | 5-60Bag/Min | 5-55Bag/Min |
Power | 220V 50/60HZ 2KW | 220V 50/60HZ 3KW | 220V 50/60HZ 3KW |
Machine Size(MM) | (L)1217* (W)1015*(H)1343 | (L)1488* (W)1080*(H)1490 | (L)1780* (W)1350*(H)2050 |
Machine Weight | About 650KG | About 680KG | About 750KG |
Option Device | Two synchronous belt device, air filling device, angle fold device, automatic rectifying device, hole-punching device, link bag device. |
Product Name:
Vertical Form Fill And Seal Machine , Fill Seal Machine , Vertical Form Fill Seal Packaging Machines , Vffs Packing Machine , Form Fill Machine , Vertical Ffs Machine , Form And Fill Machines , Vertical Form Seal Machine , Fill Seal Packaging Machine , Form Fill Seal Bagging Machine , Form Fill Seal Packaging Machine , Vertical Packing Sealing Machine , Form Fill And Seal Packaging Machines , Small Vertical Form Fill Seal Machine , Vffs Bagging Machine , Vertical Form Fill And Seal Packaging Machines , Form Fill And Seal Bagging Machine , Fill And Seal Machines,Automated Food Packaging Machine锛孲nack Food Packaging Machine 锛孨uts 鍧氭灉Filling Machine , Nuts Packing Machine Price锛孏ummy Filling Machine锛孉nhui Zengran Packaging Technology Co., Ltd.
10 Head Multihead Combination Scale锛
Main Features:
1,Original program can be restored.
2,Easy cleaning and maintenance with clean function, all hoppers can stay open.
3,Piece counting function.
4,IP65 certificate.
5,Unqualified weight reject.
6,Step motor angle can be set according to different product.
7,99 program can be preset.
8,Stagger dump prevents products blockage.
