Applications:
For materials requiring high accuracy of measurement or careful handling, e.g. puffed food, screw, or noodles.
Various bag types are available, e.g. pouch, stand-up bag, back-sealing bag, 3 or 4 sides sealing bag, linking bags,etc.
Features:
Computer control and English-Chinese touch screen for easy operation without stopping the unit.
Intelligent PID temperature controller for easy adjustment and good application to various laminated film and paper.
Packaging diversification, such as back-seal bag, side gusseted bag, linked bag, hole punched bag etc.
Full automation from bag making, measuring, filling, sealing, counting and date printing.
Multi-heads scale filling system for filling accuracy and good application to various kinds of products.
Technical Specifications:
| Model | 420 |
| Bag length | 60-300mm(L) |
| Bag width | 80-200mm(W) |
| Film width | 420mm |
| Packing material | OPP/CPP,OPP/PE,PET/LLDPE |
| Film thickness | 0.04-0.20mm |
| Packing speed | 5-60bag/min |
| Measurement range | 30-1500g |
| Pressure | 0.65Mpa |
| Gas consumption | 0.65Mpa 0.3m鲁/min |
| Voltage | 220V/60Hz single/3 phase |
| Power | 2.2KW |
| Main machine size | (L)1170mm脳(w)1500mm脳(H)1650mm |
| Main machine weight | About 450kg |
Automatic Volumetric Cup Filling Machine
Application:
The Volume Cup Filling machine good in measuring and filling free flow granular ,like rice, nuts, dry fruits, plastic piece, etc. It also can be for free flow powder, such as seasoning, fine salts, etc. It can connect with Horizontal Packing machine and Vertical Packing machine (VFFS). After adding the Pedal button, it even can work for Pre-made bags / Perform Pouch, Bottles, jars and else containers.
Features:
1. Single cup or 4/6 cups can be selected.
2. Machine frame can be Full stainless steel or Painted mild steel.
3. Cup(s) made by stainless steel or Nylon.
4. Cups filling ranges can be adjusted through hand wheel.
5. Regulation capacity of filling range is 1:2.
Product Name:
Vertical Form Fill Seal Machine , Vffs Machine , Form Fill Seal Machine , Vffs Packaging Machine , Vertical Packing Machine , Form Fill And Seal Machine , Vertical Form Fill Machine , Vertical Form Fill And Seal Machine , Fill Seal Machine , Vertical Form Fill Seal Packaging Machines , Vffs Packing Machine , Form Fill Machine , Vertical Ffs Machine , Form And Fill Machines , Vertical Form Seal Machine , Fill Seal Packaging Machine , Form Fill Seal Bagging Machine , Form Fill Seal Packaging Machine , Vertical Packing Sealing Machine , Form Fill And Seal Packaging Machines , Small Vertical Form Fill Seal Machine , Vffs Bagging Machine , Vertical Form Fill And Seal Packaging Machines , Form Fill And Seal Bagging Machine , Fill And Seal Machines.
