Applications:
Suitable for spice powder, flour, coco powder, chili powder, turmeric powder, masala powder, chemical powder, pepper powder etc automatic packaging.
Features:
1. More than 20 languages can be chose,parameter and function setting convenient with touch screen.
2. PLC intelligent control system,operation more steady without stopping machine.
3. Double frequency converter control, bag length can be set and cut at one step, saving time and film.
3. Self-diagnose function, all the fault will be display on the screen,easy to maintenance.
4. High sensitivity photoelectric eye color tracing, number input of bag size ,cutting position accurate.
5. Temperature independent PLC control, more suitable for packing different materials.
6. Positioned stop function, without sticking knife or wasting film.
7. Simple driving system, reliable working, convenient maintenance.
8. All control is realized through solfware, easy for function adjusting and technical updating.
Technical Specifications:
Machine model | ZR -320 | ZR -420 | ZR -520 | ZR -620 | ZR -720 | ZR -820 |
Bag shape | Back sealing pillow bag/4-side sealing | |||||
Packing speed | 25-80bags/min | |||||
Roll thickness | 0.05-0.15mm | |||||
Max roll width | 320mm | 420mm | 520mm | 620mm | 720mm | 820mm |
Roll diameter | 320mm | 320mm | 320mm | 320mm | 320mm | 320mm |
Bag width | 50-150mm | 60-200mm | 80-250mm | 100-300mm | 100-350mm | 120-400mm |
Bag length | 80-240mm | 80-300mm | 80-350mm | 100-450mm | 100-450mm | 120-550mm |
Voltage | 220V | |||||
Power | 2KW | 2.2KW | 3KW | 3.4KW | 3.6KW | 3.8KW |
Additional configuration | Nitrogen filling device Coding printer gas-filled device punch device etc |
Product Name:
Vertical Form Fill Seal Machine , Vffs Machine , Form Fill Seal Machine , Vffs Packaging Machine , Vertical Packing Machine , Vertical Packing Sealing Machine , Form Fill And Seal Packaging Machines , Small Vertical Form Fill Seal Machine , Vffs Bagging Machine , Vertical Form Fill And Seal Packaging Machines , Form Fill And Seal Bagging Machine , Fill And Seal Machines ,Powder Packing Machine锛孎ine Powder Filling Machine锛孭ackaging Machine Distributor , 500 Gram Packing Machine, Detergent Powder Pouch Packing Machine ,Coffee Bagging Equipment , Coffee Packaging Machine銆丳rotein Powder Packaging Machine 锛孭owder Sachet Filling Machine , Powder Sachet Packaging Machine锛孭owder Packaging Machine Price 锛學heat Flour Packing Machine 锛孎ully Automatic Flour Packing Machine锛孋heap Powder Packing Machine锛孎ood Powder Packaging Machine锛 Auger Type Powder Filling Machine锛孭owder Auger Filling Machine锛孭owder Bag Filling Machine , Powder Filler Machine 锛孷ertical Powder Packing Machine锛孭owder Packaging Machine Manufacturers锛Anhui Zengran Packaging Technology Co., Ltd.
Advantages:
1. Efficient: Bag - making, filling, sealing, cutting, heating, date / lot number achieved in one time;
2. Intelligent: Packing speed and bag length can be set through the screen without part changes;
3. Profession: Independent temperature controller with heat balance enables different packing materials;
4. Characteristic: Automatic stop function, with safe operation and saving the film;
5. Convenient: Low loss, labor saving, easy for operation and maintenance.
