Applications:
It is suitable for candy, melon seeds, jelly, frozen products, seafood, frozen fish and shrimp, frozen french fries, potato chips, meatball, pet food, puffed food, pistachio nuts, barbary wolfberry fruit, peanuts, almonds, raisins, tablet, herb, tea leaf, sugar, salt, rice, fruit, salad, screw, iron nail, powder, sheet, strip, round and irregular shape materials etc.
Features:
1. Adopting PLC from Japan or Germany to make machine run stable. Touch screen from TaiWan to make operation easy.
2. Sophisticated design on electronic and pneumatic control system makes the machine with high level of precision, reliability and stability.
3. Single-belt pulling with servo of high precise positioning makes film transporting system stable, servo motor from Siemens or Panasonic.
4. Perfect alarm system to make problem solved quickly.
5. Adopting intellectual temperature controller锛宼he temperature is controlled to ensure neat sealing.
6. Machine can make pillow bag and standing bag (gusseted bag) according to customer鈥檚 requirements. Machine also can make bag with punching hole & linked bag from 5-12bags and so on.
7. Working with weighing or filling machines such as multihead weigher, volumetric cup filler, auger filler or feeding conveyor, process of weighing, bag making, filling, date printing, charging (exhausting), sealing, counting and delivering finished product can be completed automatically.
Optional Device:
Filling nitrogen device, gusseted device, punching jaws, chain bags device, PE fillm device,venting device.
Technical Specifications:
| model | ZR-520 |
| packing speed | 10-70 bag/min |
| bag size(mm) | (W) 80-250 (L) 80-350 |
| bag making code | Pillow bag, standing bag (gusseted), punch, Linked bag |
| range of measuring(g) | 2000 |
| it is suitable for packing grain | stick |
| packing material | laminated film such as POOP/CPP,POPP/VMCPP,BOPP/ PE,PET/AL/PE,NY/PE,PET/PET |
| power parammeter | 220V 50/60Hz 3KW |
| package volume | 1430(L)脳1200(W)脳1700(H) |
| gross weight | 650kg |
Product Name:
Vertical Form Fill Machine , Vertical Form Fill And Seal Machine , Fill Seal Machine , Vertical Form Fill Seal Packaging Machines , Vffs Packing Machine , Form Fill Machine , Vertical Ffs Machine , Form And Fill Machines , Vertical Form Seal Machine , Fill Seal Packaging Machine,Automated Food Packaging Machine锛Snack Food Packaging Machine 锛Nuts Filling Machine , Nuts Packing Machine Price锛 Gummy Filling Machin锛Sugar Pouch Packing Machine銆Sugar Vertical Packing Machine锛Sugar Packing Machine Price锛Gummy Filling Machine锛1kg 2kg 5kg 10kg Sugar/Rice/Salt Packing Machine 锛Sugar Rice Salt Packaging Machine锛Sugar Filling Machine,Rice Packaging Machine Price 锛Coffee Bagging Equipment , Coffee Packaging Machine锛Beans Packaging Machine锛Chocolate宸у厠鍔 Pouch Packing Machine.
