Applications:
For Rice, Sugar, Salt, Coffee, Seeds, Nuts etc small granules.
Food: Popcorn,Tutty Fruity,Rice,Raisin,Peas,Puffed Rice,Oatmeal,Pistachio,Peanuts,Melon Seeds,etc.
Seasoning: Pepper granule,Ajinomoto,Salt,Sugar,etc.
Chemical Products: Oxygen absorber granule,Desiccant granule,Dry powder,Pesticide Granule ,etc.
Medical: Pill,Tablet,Medicine,etc.
Features:
High-speed capabilities up to 80 packs per min
Adjustable capacity from 50-250ml; 250-500ml, 500-1000ml is optional
Accuracy 0.2 to 2g
Omron controls as standard
User-friendly interface
Film track by photo-electric eye & encoder
Servo driven for film transport
Stainless steel systems
Small footprint, Compact, robust and long-life construction
Customized to meet your production, package style and econoic requirements
Optional Device:
Filling nitrogen device, gusseted device, punching jaws, chain bags device, PE fillm device,venting device.
Technical Specifications:
| Type | ZR-420 | ZR-520 | ZR-620 | ZR-720 |
| Packaging speed | 10-80bags/min | 10-70bags/min | 10-50bags/min | 10-50bags/min |
| Bag size(mm) | L:50-300 W:80-200 | L:80-350 W:90-250 | L:90-400 W:100-300 | L:100-420 W:110-350 |
| Bab type | Pillow bag,stand up pouch,pillow with hole pouch,continuous bag | |||
| Measuring range(ml) | 150-1500 | 2000 | 3000 | 4000 |
| Max film width(mm) | 420 | 520 | 620 | 720 |
| Film thickness(mm) | 0.04-0.10 | |||
| Air comsumption | 0.4m3/min 0.6MPa | 0.4m3/min 0.6MPa | 0.8m3/min 0.8MPa | 0.8m3/min 0.8MPa |
| Power source | 2.5KW/220V 50-60HZ | 3KW/220V 50-60HZ | 4KW/220V 50-60HZ | 4KW/220V 50-60HZ |
| Weight(kg) | 450 | 650 | 800 | 800 |
| Overall size(mm) | 1400*970*1700 | 1430*1200*1700 | 1780*1350*2000 | 1780*1350*2000 |
| Packaging material | Heat-sealable composite film (OPP/CPP OPP/CE MST/PE PET/PE) | |||
Product Name:
Form Fill And Seal Bagger, Form Fill Seal System , Form Fill Seal ,Vertical Form Fill Seal Bagger , Automatic Form Fill Machine ,, Conveyor Belt Packaging Machines , Vertical Form Fill And Seal Machines , Vffs Parts , Single Serve Packaging Machine , Vertical Form Fill , Automatic Packing And Sealing Machine,Salt Bagging Machine , Salt Machine Price锛 Rock Salt Bagging Machine 锛孉utomatic Salt Packing Machine锛1kg 2kg 5kg 10kg Sugar/Rice/Salt Packing Machine锛孲ugar Rice Salt Packaging Machine锛500 Gram Packing Machine.Granule Packing Machine Factory锛孯ice Packaging Machine Price 锛孋offee Bagging Equipment , Coffee Packaging Machine锛孊eans Packaging Machine锛孋hocolate Pouch Packing Machine锛孲ugar Pouch Packing Machine锛孲ugar Vertical Packing Machine锛孋offee Packaging Factory锛孉utomatic Seed Packaging Machine锛孊eans Packing Machine Price 锛孲eed Filling Machine锛孲eed Packaging Machine锛孏ummy Filling Machine锛1kg 2kg 5kg 10kg Sugar/Rice/Salt Packing Machine 锛
Anhui Zengran Packaging Technology Co., Ltd.
FAQ:
Make sample bags.
If it's necessary according to your requirements, we can make sample bags for your reference.
Machine adjustment before shipment.
Our technical team will adjust the machine based on customer's request and take video to send to our customer to show the running condition of the machine.
Training CD to ship with machine.
Our technical team will provide a trainning CD to our customer in order to train how to use the machine.
Life Long after sale service.
Our factory will provide life long service, in order to help our customer to solve any problem regarding to the machine, such as replacement part, technique questions, etc.
Overseas door to door service.
Our engineer overseas door to door service is available.
Warranty and after-sales service.
One year warranty, 24 hours online technical service and solution can be offered.
