Applications:
It's suitable to use in packing the high accuracy and easy fragile material , such as : such as milk powder, flour, soybean powder, medicine powder, etc
Features:
adopts the advanced PLC control system, touch screen in both Chinese and English, and automatic completion of measuring, bag making, filling, sealing, cutting and printing codes.
adopts the stainless steel 201 for the machine's mainframe, and stainless steel 304 for the parts touching supplies, which has a very good effect of anti-rusting, so guarantee the products clean and sanitary, and also greatly prolong the machine's life-span.
Fully sealed for the machine mainframe, keep the powder supplies clean and sanitary.
Technical Specifications:
| Item | fully automatic powder spice packaging machine |
| Model | ZR-420 |
| Filling | screw |
| Bag style | Back sealed bag,pillow bag |
| Volume/bag | 200-2000ml/bag |
| Bag size | L80-300mm, W50-200mm |
| Packing speed | 15-40 bags/min |
| Control system | PLC+ touch screen |
| material | stainless steel |
| Pneumatic | 0.6Mpa, 30L/min |
| voltage | 380V, 50Hz,3P/ 220V, 60Hz, 3P |
| Weight | G.W. 850kg |
| Dimension | L1330*W1140*H2460 (mm) |
| Power | 2.5KW |
| Film material | Paper/polyethylene; cellophane/polyethylene; Plated aluminum/polyethylene; BOPP/polyethylene; nylon/polyethylene |
| supplies | fine Powder, such as milk powder, flour, soybean powder, medicine powder, etc |
| Main functions | Automatically measure, make bags, fill, seal, cut and print codes. |
| Model | Auger filler |
| Weighing range | 10~5000g(One auger screw for one differeng weight range) |
| Weighing accuracy(g) | Range<100g, deviation: 0.5~1g |
| Range: 100~5000g, deviation: 0.5~1% | |
| Filling speed | 10~50 bags per minute |
| Material hopper | 50L |
| Voltage | 220V/380V |
| Gross weight | 200Kg |
