Applications锛
Food: Candy,Beans,Chips,Popcorn,Pasta,Corn,Rice cake,Jelly,Cookies,Cheese,Peanuts,Coffee Creamer,Almond,etc.
Daily necessities: Mothballs,Disposable Mask,Buttons,etc.
Hard&Ware: O ring,Screw,Dowel,etc.
Medical: Pill,Medicine,etc.
Features锛
* Low input high gain, high speed and efficiency.
* International brand PLC control system, large touch screen, convenient to operate.
* Film drawing down system with servo motor and horizontal sealing controlled by cylinder, Minimize the loss with complete automatic warm protection function.
* High automatic, it can complete feeding , measuring, filling, sealing, date printing ,filling nitrogen, counting, transporting the finished products.
*Bag type: Pillow bag and gusseted bag.
Optional Device锛
Filling nitrogen device, gusseted device, punching jaws, chain bags device, PE fillm device,venting device.
Technical Specifications锛
Speed | 45-50 bags/min |
Bag size/Filling range | (L)50-300mm (W)50-220mm / 100g-50kg per bag |
Bag type | Pillow bag, (option:gusseted bag, punching bag) |
Film width | 460mm |
Film thickness | 0.04-0.9mm |
Air consumption | 0.5cmb/min 0.8MPa |
Power | 2.2KW/220V 50Hz |
Dimension | L1830*W1369*H2671.5mm |
Weight | 877kg |
Product Name:
Rice Packaging Machine Price 锛1kg 2kg 5kg 10kg Sugar/Rice/Salt Packing Machine 锛Sugar Rice Salt Packaging Machine,Automated Food Packaging Machine锛Snack Food Packaging Machine 锛Nuts Filling Machine , Nuts Packing Machine Price锛Gummy Filling Machine,Coffee Bagging Equipment , Coffee Packaging Machine锛Packaging Coffee Machine锛Coffee Packaging Factory,Beans Packaging Machine锛Beans Packing Machine Price,Sugar Pouch Packing Machine銆Sugar Vertical Packing Machine锛Sugar Packing Machine Price锛 Gummy Filling Machine锛1kg 2kg 5kg 10kg Sugar/Rice/Salt Packing Machine 锛Sugar Rice Salt Packaging Machine锛Sugar Filling Machine ,Pasta Packaging Machine.
Linear Scale Weigher锛
Flexibility and versatility to weigh fine granulates and coarse powder products, range from 100G up to 5KG; Bulk model up to 50KG
The CJS2000 Series Linear Weigher have been continuously developed over many years with model from single to six heads. Now to be the most versatile and accurate linear weighers for different application.
CJS-2000 series linear weigher is easy operating and both applied in semi-automatic packaging line or full automatic packaging machinery.
Double channel feeding for each bucket bring high speed and high accuracy.
Various options are made available to meet specific requirements. Digital sensor enhance the speed, precision and anti-jamming capability.
Ideally suited for slice, roll or regular shape products: sugar, salt, seed, rice,sesame, glutamate, milk powder, coffee and seasoning powder, etc.
Principal Feature锛
Adopt high precision digital load cell
Stable PLC system control
Color touch screen with Multilanguage control panel
Sanitation with 304# S/S construction
The parts contacted products can be easily mounted without tools
IP65 grade construction
Make mix different products weighing at one discharge
Adopt no-grade vibrating feeding system to make products flowing more fluently
Program can be freely adjusted according to production condition
Can be remote-controlled and maintained through internet
