Applications:
It is suitable for packing powder product such as milk powder, wheat flour, coffee
powder, tea powder, bean powder.
Features:
1.Imported PLC computer control system with human-machine interface; touch screen is simple and direct-viewing in operation;
2.precise positioning with servo film transporting system; excellent complete machine performance and nice packing;
3.minimize the loss with complete automatic warn protection function;
4.supported with metric device, the machine will automatically complete all packaging processes from measuring, feeding, filling, bag ma
5.the way of bag making: the machine can make pillow-type bag and standing bag according to customer’s requirements.
6.It could pack different kind of granule ,puffed food, rice, sugar etc.
7.Related machine as milk powder packing machine, 1kg flour bag packaging machine, corn flour packaging machine, coffee powder packing machine etc.
·Humanized safety design,automatic stop when the work doors are opened,which can avoid industrial injury to a great extent.
·Transparent acrylic windows are applied on four sides,so that you can see each part of the machine from each side when operates.You can know the situation of the machine whenever,which make it convenient to maintain.
·Imported Janpanese Panasonic PLC(HMI), servo motor to draw film,that bring you high accuarcy,simple operation,long service life and stable production.
·Automatic fault alarm system,automatic stop when doors are opened.Safe and reliable.
·The structure's simplicity improves performance and saves power to some extent,so that impoves the production efficiency, reduces the cost of labour to achive low production cost for enterprise.
·The accessories of are supplied by large-scale renowned manufacturer,which insures you stable performance.
·The design is up to the food standard and safety standard completely.
Optional Device:
Filling nitrogen device, gusseted device, punching jaws, chain bags device, PE fillm device,venting device.
Technical Specifications:
Items | Content |
Packing speed | 20-70 bag/min |
Bag size | (L)60-300mm (W)80-200mm |
Bag making mode | Pillow-type bag, standing bag, punch |
Range of measuring | 150-1000ml |
Max packaging film width | 420mm |
Thickness of film | 0.04-0.08mm |
Air consumption | 0.8 Mpa 0.5m/min |
Main power/voltage | 2.2KW/220V 50-60Hz |
Dimension | 1320×920×1392mm |
The weight of switchboard | 450kg |
Product Name:
