Applications锛
All kinds of grain material, sheet material, strip material and abnormity material which such as candy, melon seeds, chips, peanut, nutlet, preserved fruit, jelly, biscuit, confect, camphorball, currant, almond, chocolate, filbert, corn, Potato Crisps, pet foodstuff, dilatant foodstuff, hardware and plastic can be weighed by the ration.
Features锛
Efficient: Bag - making, filling, sealing, cutting, heating, date / lot number achieved in one time;
Intelligent: Packing speed and bag length can be set through the screen without part changes;
Profession: Independent temperature controller with heat balance enables different packing materials;
Characteristic: Automatic stop function, with safe operation and saving the film;
Convenient: Low loss, labor saving, easy for operation and maintenance.
Optional Device锛
Filling nitrogen device, gusseted device, punching jaws, chain bags device, PE fillm device,venting device.
Product Name:
Vertical Form Fill Seal Machine , Vffs Machine , Form Fill Seal Machine,500 Gram Packing Machine, , Plastic Pouch Packing Machine ,Paper Filling Machine , Small Weighing And Packing Machine , Vffs Baggers , Pouchfill Packaging , Full Automatic Packaging Machine , Pouch Bag Packaging Machine , Vertical Fill And Seal Machines , Automatic Bag Filling And Sealing Machine , Chips Pouch Packing Machine , Vertical Form Fill Seal Machine Manufacturers , Nitrogen Bagging System , Vffs Machine Manufacturers , Automatic Atta Packing Machine Manufacturers , Form Fill And Seal Plastic ,Automated Food Packaging Machine锛孲nack Food Packaging Machine 锛孨uts Filling Machine , Nuts Packing Machine Price锛 Gummy Filling Machine,Beans Packaging Machine锛孊eans Packing Machine Price,Granule Packing Machine Factory.
Technical Specifications锛
Model | ZR-420 | ZR-520 | ZR-720 |
Film Width | Max.420MM | Max.520MM | Max.720MM |
Bag Length | 80-300MM | 80-350MM | 100-500MM |
Bag Width | 60-200MM | 100-250MM | 180-350MM |
Film Roll Diameter | Max.320MM | Max.320MM | Max.320MM |
Film Thickness | 0.04-0.12MM | 0.04-0.12MM | 0.04-0.12MM |
Packing Speed | 5-60Bag/Min | 5-60Bag/Min | 5-55Bag/Min |
Power | 220V 50/60HZ 2KW | 220V 50/60HZ 3KW | 220V 50/60HZ 3KW |
Machine Size(MM) | (L)1217* (W)1015*(H)1343 | (L)1488* (W)1080*(H)1490 | (L)1780* (W)1350*(H)2050 |
Machine Weight | About 650KG | About 680KG | About 750KG |
Option Device | Two synchronous belt device, air filling device, angle fold device, automatic rectifying device, hole-punching device, link bag device. |
PARTS | SUPPLIER |
PLC | Panassonic |
Touch Screen | Weinview |
Servo Motor | Panassonic |
Servo Driver | Panassonic |
Solid state Relay | Crydom |
Intermediate Relay | Omron, IDEC |
Switching power supply | Schneider |
Air Cylinder | AIRTAC |
Gear Motor | V.T.V |
Electromagnetic Valve | SMC |
Pneumatic FRL | SMC |
Sensors & controllers | AUTONICS |
