Applications
Powder and fine granular products such as food additives,condiments, tapioca powder, coconut powder, pesticide powder, fertilizer granules etc.
Main Features
Safety guard protected for highspeed and consistent production.
Heavy duty components and parts areselected for machine durability.
Hygienic construction and easycleaning (wash down construction on special request).
Operators friendly design in touch-screencontrol system.
Versatile in design, easy to link upwith other down stream packaging equipment such as multiheads weigher, metaldetector, check weigher, case sealer etc.
Complying with GMPstandard, all product contact parts are in stainless steel or food gradematerials, guarantee hygiene and security of the food.
Innovative and practical solution atreasonable costs.
Technical Parameters
| Model | ZRG6-200 |
| Bag type | All type of heat sealable preformed side seal bags, fin seal bags, gusseted bags, block bottom bags, zip-lock re-closeable bags, stand-up pouch with or without spout etc. |
| Bag size | W:100~200mm L:100~300mm |
| Filling volume | 5-1500g |
| Capacity | 25-45bags/min (depending on type of product and filling weight) |
| Accuracy | 鈮ぢ1 |
| Total power consumption | 3.6Kw |
| Application | Powder and fine granular products such as milk powder, coffee powder, food additives, condiments, tapioca powder, coconut powder, pesticide powder, fertilizer granules etc. |
| Optional equipment | Automatic Auger Filler, Volumetric Cups Filler etc. |
| Note: other specifications available | |
Product Name:
Anhui Zengran Packaging Technology Co., Ltd锛Rotary Packing Machine , Filling Machine For Nuts , Flour Paper Bag Packing Machine , Rotary Pouch Filling Machine , Doypack Sealing Machine , Doypack Filling And Sealing Machine , Stand Up Bag Filling Machine , Automatic Stand Up Pouch Packing Machine , Premade Pouch Filling Sealing Machine , Stand Up Pouch Filling Equipment , Stand Up Pouch Filling Machine , Zipper Pouch Machine , Doypack Pouch Filling Machine , Zipper Pouch Sealing Machine , Rotary Bagger
BAG OPENINHG
Pouches are individually removed from the cartridge with a unique combination of vacuum and pneumatic actuators. They are rotated to the fill area and opened.
TRANSITION CHUTE
doubling as a timing bucket. product enters the transition chute while the bag is being opened below. Upon pouch detection the chute enters the bag and opens its gate. Product is dispensed immediately, without spillage and protecting the seal from contamination. Difficult product that easily bridges is dispensed into the pouch directly from the filler, through the "open-gate''
FILLING
During filling, pouches are held in place with our鈥減osi-hold鈥 gripper system. This allows for heavy weights and shock loads
without disturbing bag Position
SEALING
Digitally controlled ribbed or flat constant heat seal bars give a integral attractive seal. Pouches are sealed ''in place" eliminating wrinkles, folded corners and non aligned seals
MECHINE CONTROLS
System controls are fully solid state. utilizing a commercial Programmable Logic Controller [PLC] and pneumatics. Indicator lights signal all cycle processes for easy monitoring.
