Applications
Equipped with Z-shape bucket elevator and combination scale, it is widely applied to candies, microwave popcorn, cookies, nuts, rice, coffee beans, crops, peanuts, etc.
8 work stations:
1) bag picking;
2) coding;
3) zip unit;
4) bag opening;
5) according to the material;
6) according to the material;
7) sealing and closing zip;
8) tidy to output;
Features
Easy To Operate: PLC control, man-machine interface.
Frequency Conversion Speed Regulation: Using frequency conversion adjustment device, the speed can be adjusted at will in the specified range.
Easy to adjust the clip width: Control by motor; Only by a button you can sync control 8 sets of clip.
The material level is all made of stainless steel 304 or food-degree plastic according with food hygienic requirement.
Open Zipper Mechanism: Design for zipper bag characteristics, high opening rate (invention patent).
Technical Data
| Model | ZR-200 | ZR-300 |
| Working Stations Number | Eight | |
| Pre-made Pouch Types | Heat sealable premade side seal bags, like gusseted bag, flat bottom bags, zipper bags, stand-up bags, spout bags, etc. | |
| Pre-made Pouch Size | Width: 80 to 220mm (3.15鈥 to 8.66鈥) | Width: 180 to 300mm (7.09鈥 to 11.81鈥) |
| Length: 100 to 300mm (3.94鈥 to 11.81鈥) | Length: 100 to 350mm (3.94鈥 to 13.79鈥) | |
| Capacity | 35 to 40bpm (depending on product and pouches) | |
| Filling Range | 10 to 2500g (depending on the product) | |
| Power Consumption | 2.5kw | 2.1kw |
| Air Consumption | 0.6 m鲁/min (supplied by the user) | |
| Outer Dimension | 1460*2500*1400mm | 2460*1835*1640mm |
Product Name:
Zengran Packaging 锛Rotary Packing Machine , Filling Machine For Nuts , Flour Paper Bag Packing Machine , Rotary Pouch Filling Machine , Doypack Sealing Machine , Doypack Filling And Sealing Machine , Stand Up Bag Filling Machine , Automatic Stand Up Pouch Packing Machine , Premade Pouch Filling Sealing Machine , Stand Up Pouch Filling Equipment , Stand Up Pouch Filling Machine , Zipper Pouch Machine , Doypack Pouch Filling Machine , Zipper Pouch Sealing Machine , Rotary Bagger.
Our Services
1) Warranty Time: 1 year, within this period we offer spare part replacement freely if there are any Non-artificial damage on them.
2) Quality: Quality of products will be strictly checked and every machine will be test to ensure it can works well before packaging.
3) Technical services: We will keep contacting with our customers all the time after selling out the machine. Please contact us without hesitation if you need any help on machines.
4) File Services: We offer instruction manual and video to teach you how to using and testing machine.
5) Accessories: We supply spare parts with competitive price after warranty time.
