Applications
Rice, Wheat, Pulses, Granules, Powder, Chemicals etc.
It is Fully Automatic Milk Glucose Powder Bagging System With Robot Palletizer Plant in industries such as chemistry, fertilizer, grain, food, feed, medicine, construction materials industry, etc.
fully automatic packing machine for open-mouth bags with high degree. It can be used for packaging of bags with various materials, particularly for woven bags with plastic coating. The packaging lines have been well received in Thailand SIAM Company, one of the largest rice processing factories in the world. The packaging line is composed if automatic weighing packaging machine, automatic packaging machine, mesh-belt conveyor, bag feeding machine, reversing bag flattener and control system, etc.
A whole set of processing procedures including materials transmission, weighing, filling, packaging, bag flattening, sealing, sewing and conveying can be finished by the machines. Our machines can be made to order and designed according to customer's requirement.
FEATURES
allows it to reach up to 15 BPM
Rapid and reliable
Low maintenance
Requires little floor space
Optimum reliability
Quick and easy to install and start up
Reduces the number of injuries among workforce
Compatible with every closing system
Main Components:
1. Automatic quantity-fixed balance
2. Automatic bag-supply section
3. Optional section such as air compressor
4. Automatic bag-clamped section
5. Automatic belt conveyor
6. Automatic sewing / sealing machine
7. Automatic bag-backwards section
8. Electrical instrument control cabinet
Characteristics:
1. Picking bag, feeding bag, filling material, weighing in , sewing / sealing bag, bag-backwards and bag transmission are finished completely automatically.
2. Adopting PLC to guarantee the reliability of control
3. Adopting high-precision transducer and intelligent instrument to guarantee the accuracy and speed of weight
4. Adopting touch screen with trouble display and help system for easy operation.
5. Adopting imported pneumatic components features compact structure, reliable performance and convenient maintenance.
6. The sewing / sealing machine is an imported machine.
Technical Parameters
| MODEL | ZRCK-25K | |
| Packaging | Object | granular material |
| Material | 1- paper bag | |
| 2- woven bag(lined with PP/PE film) | ||
| 3- plastic bag(film thickness 鈮0.2mm | ||
| Dimension | (700-850)*(400-500)mm (L*W) | |
| Weight | granular material 10- 25kg | |
| Seal Type | Woven bag | lura folding/seaming |
| Kraft paper bag | sealing/seaming | |
| Composite film bag | sealing | |
| Machine | Speed | 5 - 15 bags/min (adjustable) |
| Measurement Accuracy | 卤 50g | |
| Air Supply | 0.5 - 0.7 Mpa | |
| Power | 4.0kw 380v 卤 10% 50Hz | |
| Machine Package | Dimension | 4300*3500*3700mm |
| Weight | 1400kg | |
Product Name:
Auto Baggers , Bagging Plant For Sale , Bagging Machine For Sale , Chemical Packaging Equipment , 5kg-10kg cat litter packing machine , Fertilizer Bagging Equipment For Sale , Open Mouth Bagger For Sale , Auto Bagger For Sale , Paper Bag Packing Machine , Automatic Bagging Equipment , Bagging Station , Cannabis Bagging Machine , Sunflower Seed Packing Machine , Big Bag Handling Equipment , Sugar Hopper Equipment , Packing Conveyor Machine , Packaging Machinery Manufacturers Europe , Packaging Machine Drawing , Salt Packing Machine , Sugar Packing Machine Video , Automatic Bagging Machine , Compost Bagger For Sale , Automatic Packing Machine For Sale , Soil Bagging Machine , Open Mouth Bagging Equipment , Automatic Packaging Machine , Open Mouth Bag Packaging Machine , Bagging Machine For Open Mouth Bag , Intelligent Packaging Machine , Bagging Equipment , Sandbag Filling , Sandbag Filling Machine , Animal Feed Bagging , Animal Feed Bagging Machine , Automated Packaging Systems , 25kg Sugar Bagging , 25kg Sugar Bagging Machine
After sales service
1. Providing professional installation instructions and video of troubleshoot.
2. Providing machine control software updates and operation teaching in our factory.
3. Two years free maintenance for touch screen,inverter,PLC, temperature controler,photoelectric sensor with freight prepaid.
4. Engineers available to service the machinery overseas, buyers pay 120 US dollars daily service fees and travel expenses.
