Features:
1. Using PLC and man-machine interface, easy to program control
2. The man-machine interface embodies the concept of people-oriented, with the relevant graphical button display program and the sensor actuator, a set of parameters storage function, and provide a simple method of handling and use
3. This machine consists of manually entered into the bottle mouth, in order to complete the whole bottle, bottle feeding and positioning, bottle positioning, feeding positioning, automatic filling the bottle. The whole process automatically, in full compliance with the GMP certification requirements.
Application:
Beverage, Chemical, Food, Machinery & Hardware, Medical
Technical parameters:
Place of Origin: Voltage: 220V
Power: <1kw (including intermittent power)
Product name: Dimension(L*W*H):2440*1100*2350mm
Weight: 500kg
Capacity: 2700 bottles/hour
Material: Stainless Steel 304
Filling accuracy: 卤1.0mm
Suitable height of bottles: 50-330mm
Irrigation range: 50-3000ml
Procedure control: PLC+ touch screen
Conveying belt speed: 5-15 meter/min
