Overview:
The machine is mainly used in the canning industry, the bag, empty bottles, tin cans, aluminum cans and glass bottles of empty tank palletizing operations. First in the demolition of the board with the stack will be stacked out of the stack into the main room. At this time the palletizing machine through the network conveyor automatically arranged by the tank, the use of sub-tank device will be finished empty cans in accordance with the required empty canned body size of the whole column, and then by the tank device to empty the tank to the pallet master room , And finally by the main room of the lifting mechanism to complete the layered tank action. When the stack is good, the empty canned body is sent to the automatic winding film machine for film winding for easy storage and delivery. The whole work process has automatic demolition board, board, lift, automatic sub-tank, code tank, automatic drop, stacking, automatic winding film, etc., to replace the artificial code tank way, save manpower, greatly improve production efficiency.
Excellent performance:
1. To replace the traditional artificial cans and semi-automatic empty tank cans, can save a lot of labor, improve production capacity;
2. Using PLC control system to improve the accuracy of mechanical action, and easy to operate;
3. High degree of automation, can achieve "control system";
4. Applicability is wide, can use a variety of cans and so on.
Device function configuration:
1. Automatic demolition mechanism:
2. Automatic pallet raising mechanism;
3. Automatic sub-tank device;
4. Automatic holding machine;
5. empty canned chain conveyor;
6. Air pallets to the chain conveyor;
7. Automatic separation of cardboard bodies;
8. Using Mitsubishi (MITSUBISHI) PLC programmable computer automatic controller, SICK (SICK) photoelectric switch and other famous brand products, equipment stability, superior performance.
Technical Parameters:
Removable size: maximum height 1500mm, or custom
Applicable tray width 1000mm 脳 length 1200mm or width 1100mm 脳 length 1400mm;
The machine plc programmable computer automatic controller, photoelectric switch, travel switch, pneumatic
Control, etc. are used in Germany, Japan and other countries well-known brand products;
Applicable object size: Applicable object size: diameter 50mm - diameter 153mm, height 50mm - height 150mm;
Applicable objects: all kinds of tin cans, glass bottles, plastic bottles, etc.
Dimensions: length 9.5m 脳 Width 1.5m 脳 height 2m;
Power parameters: 3phase 380v, 9kw
