Application:
Applicable for weighing of granular or small dose products with good flowability.
Main Function Features:
1. Professional digital weighing modular with high precision and good stability.
2. Operation authorization set-up in HMI; 16 languages to be selected, application software upgraded through USB.
3. Restoration function of factory parameter. 99 product parameters can be preset to meet different parameter program requirements.
4. Weighing hopper able to discharge in turn, effectively prevent products from blocking.
5. Real-time display of amplitude of each vibration pan as well as product weight in each hopper to better monitor the running status of machine.
6. Machine body with SUS304/316 for option, IP65 dust and waterproof design.
7. Cleaning Function: able to let the hoppers stay in opening for easy daily cleaning and maintenance.
8. Modular design of control system for easy maintenance and cost-saving.
9. 2-6 blended product weighing.
10. Able to keep good ratio precision of each blended product and high accuracy of the total
Specifications:
Model | ZY-32-0.8, ZY-32-1.6, ZY-32-2.5 |
Max. Weighing (one hopper) | 1000g |
Accuracy | x (0.5) |
Max. Scale Interval | 0.1g |
Max. Speed | 30~80 WPM |
Hopper Volume | 0.8L锛1.6L锛2.5L |
Control System | MCU / PLC |
HMI | 10鈥欌 color touch screen |
Power Supply | AC220V 卤10% 50HZ/60HZ, 3KW |
Packing Dimension | 1,430(L)*1,430(W)*1,508(H)mm |
Net Weight | 760kg |
Gross Weight | 800kg |
